ARINC 429 线接收器
GENERAL DESCRIPTION
The ARINC 429 Line Receiver converts ARINC 429 differential RZ data to TTL/CMOS compatible outputs. Each lightning protected receiver channel operates independently and meets all requirements of the ARINC 429 Digital Information Transfer Standard. Please refer to the selection table below for Data Sheets.
ARINC LINE RECEIVER BLOCK DIAGRAM
型号:DEI1041
DEI1041 ARINC 429 线接收器
· ARINC 429 to TTL/CMOS logic line receiver
· Drop-in replacement for HI-8588 and HI-8588-10
· Operates from single 5 V ±10% or 3.3 V ±10% power supply
· ARINC inputs internally protected to lightning requirements of DO-160 Level 3 pin injection
· ARINC inputs withstand inadvertent short to 115 Vac on inputs
· Operates in high noise environment
o Input Common Voltage Range: ± 20 V
o 2 V minimum Input hysteresis
· Logic level TEST inputs bypass analog inputs.
· High input resistance allows use of external series resistors to support:
o Lightning protection beyond Level 3
o Fault isolation
· Package: 8L SOIC
· Drop-in replacement for HI-8588 and HI-8588-10
· Operates from single 5 V ±10% or 3.3 V ±10% power supply
· ARINC inputs internally protected to lightning requirements of DO-160 Level 3 pin injection
· ARINC inputs withstand inadvertent short to 115 Vac on inputs
· Operates in high noise environment
o Input Common Voltage Range: ± 20 V
o 2 V minimum Input hysteresis
· Logic level TEST inputs bypass analog inputs.
· High input resistance allows use of external series resistors to support:
o Lightning protection beyond Level 3
o Fault isolation
· Package: 8L SOIC
型号:DEI3283
DEI3283 双通道 ARINC 429 线接收器
· Two separate analog receiver channels
· Converts ARINC 429 levels to serial data
· ARINC 429 inputs withstand +/-200 V
· TTL inputs to test complete analog/digital RX function
· TTL and CMOS compatible outputs
· Low power dissipation
· Internal band gap voltage reference
· MIL-STD-883B burn-in screening available
· Package Options: 20 Lead ceramic DIP, 20 Terminal ceramic LCC, and 20 Lead SOIC
· Direct replacement for Fairchild/Raytheon RM3283 and RM3183 and Holt HI-8482
· Converts ARINC 429 levels to serial data
· ARINC 429 inputs withstand +/-200 V
· TTL inputs to test complete analog/digital RX function
· TTL and CMOS compatible outputs
· Low power dissipation
· Internal band gap voltage reference
· MIL-STD-883B burn-in screening available
· Package Options: 20 Lead ceramic DIP, 20 Terminal ceramic LCC, and 20 Lead SOIC
· Direct replacement for Fairchild/Raytheon RM3283 and RM3183 and Holt HI-8482
型号:DEI1044A/DEI1045A
DEI1044A, DEI1045A 四通道 ARINC 429 线接收器
Quad ARINC 429 to TTL/CMOS logic line receivers
· Drop-in replacement for DEI1044 / DEI1045
· Drop-in replacement for HI-8444/5PS_, HI-8444/5PS_ -10 & HI-8454/5PS_
· Operates from single +5 V or 3.3 V power supply
· ARINC input internally protected to lightning requirements of DO-160 level 3 pin injection
· ARINC inputs withstand inadvertent short to 115 Vac
· Operates with optional external serial resistors on the ARINC inputs up to 15 kΩ
o Supports lightning protection beyond level 3
o Provides resistive fault Isolation
· Operates in high noise environment
o ±20 V input common mode voltage range
o 2 V minimum input hysteresis
· DEI1044A has TTL/CMOS test inputs
· Package: 20L 4.4 mm TSSOP
· Drop-in replacement for DEI1044 / DEI1045
· Drop-in replacement for HI-8444/5PS_, HI-8444/5PS_ -10 & HI-8454/5PS_
· Operates from single +5 V or 3.3 V power supply
· ARINC input internally protected to lightning requirements of DO-160 level 3 pin injection
· ARINC inputs withstand inadvertent short to 115 Vac
· Operates with optional external serial resistors on the ARINC inputs up to 15 kΩ
o Supports lightning protection beyond level 3
o Provides resistive fault Isolation
· Operates in high noise environment
o ±20 V input common mode voltage range
o 2 V minimum input hysteresis
· DEI1044A has TTL/CMOS test inputs
· Package: 20L 4.4 mm TSSOP
型号:DEI1046A
DEI1046A 八通道 ARINC 429 线接收器
Octal ARINC 429 to TTL/CMOS logic line receivers
· Drop-in replacement for DEI1046-T_S-G and HI-8456PS_
· Operates from single +5 V ± 10% or 3.3 V ± 10% power supply
· ARINC inputs internally protected to lightning requirements of DO-160 Level 3 pin injection
· ARINC inputs withstand inadvertent short to 115 Vac on inputs
· Operates in high noise environment
o Input Common Voltage Range: ± 20 V
o 2 V minimum Input hysteresis
· High input resistance allows use of external series resistors to support:
o Lightning protection beyond Level 3
o Fault isolation
· Package: 38L TSSOP, 4.4 mm body
· Drop-in replacement for DEI1046-T_S-G and HI-8456PS_
· Operates from single +5 V ± 10% or 3.3 V ± 10% power supply
· ARINC inputs internally protected to lightning requirements of DO-160 Level 3 pin injection
· ARINC inputs withstand inadvertent short to 115 Vac on inputs
· Operates in high noise environment
o Input Common Voltage Range: ± 20 V
o 2 V minimum Input hysteresis
· High input resistance allows use of external series resistors to support:
o Lightning protection beyond Level 3
o Fault isolation
· Package: 38L TSSOP, 4.4 mm body
型号:DEI1148
DEI1148 八通道 ARINC 429 线接收器
· Octal ARINC 429 to TTL/CMOS logic line receivers
· Operates from single +5 V ± 10% or 3.3 V ± 10% power supply
· Operates in high noise environment
o Input Common Voltage Range: ± 20 V
o 2 V minimum Input hysteresis
· ARINC inputs internally protected to lightning requirements of DO-160 Level A3
· Withstands inadvertent short to 115 Vac on inputs
· Package: 44L MQFP, 13.9mm footprint
· Operates from single +5 V ± 10% or 3.3 V ± 10% power supply
· Operates in high noise environment
o Input Common Voltage Range: ± 20 V
o 2 V minimum Input hysteresis
· ARINC inputs internally protected to lightning requirements of DO-160 Level A3
· Withstands inadvertent short to 115 Vac on inputs
· Package: 44L MQFP, 13.9mm footprint
