Input Voltage Range: 18-40 Volts dc

DC Outputs: 5V@2A; 15V@0.4A; -15V@0.4A
Input Power Characteristics: MIL STD. 704E, transients as pre Fig 9, including voltage spikes specified in MIL-E6051. DEF STAN 61-5 Part 6 (A1, A2, B1, B2). MIL STD 1275A, excluding the single fault condition, survival only.
Isolation:  Input to Output >10 Mohms+@500Vdc
                       Input to Chassis >10 Mohms+@500Vdc
                      Output to Chassis >10 Mohms+@100Vdc
Efficiency: Not less than 75% at full load, 28 volts dc input and at 25 deg C
ambient temperature.
Load Line and Temperature Regulation: +/- 2% of output voltage
Minimum Load Condition: 5% of maximum current on prime output.
Output Protection:

Output is protected against indefinite overload and short circuit.
Power limiting circuitry operates at 110%-130% of full rated power.
Output voltage recovers automatically when the overload is removed.
O/P PARD: 50mV pk-pk DC -20 MHz
Under Voltage Lockout: To protect internal circuits against low input voltages, the converters will not operate below an input voltage of 15V dc.
EMI:

The units are designed to meet the following requirements of MIL STD 461C, Part 2, category A1b: CE01, CE03, CS01, CS02, CS06, RE02, RS02, RS03.
Operating Temperature: -40 deg C to +80 deg C case temperature
Storage Temperature: -55 deg C to +90 deg C
Dimensions: 74 x 51 x 13mm
Weight: 100 grms
MTBF (predicted): 100,000 Hours AIF 50 deg. C
Shock: 20g for 30 ms, 40g for 9mS
Start up: <50ms from application of input power
Output inhibit functions by connecting INHIBIT pin to 28V return
