Civil Aerospace-Sub-Assemblies

Model No.:1-09435
1-09435 10 Watt Single Output DC/DC Converter
DC Input: 18-80 Volts
DC Output: 5V at 2Amps
Dimensions: 69 X 51 X 19mm
Model No.:CDA/B/C/G/H-120
CDA/B/C/G/H-120 120 Watt DC/DC Converter
DC input: 18 - 32 Volts
CDA-120: 5V@24A
CDB-120: 0+/-12V@5A
CDC-120: 0+/-15V@4A
CDG-120: 12V@10A
CDH-120: 15V@8A
Model No.:1-09364
1-09364 15 Watt Triple Output DC/DC Converter [DC-DC]
DC Input: 18-40Vdc
DC Outputs: 5V@2A; 15V@0.4A; -15V@0.4A
Dimensions:: 74 X 51 X 13 mm
Model No.:CDA/B/C/G/H-30
CDA/B/C/G/H-30 30 Watt DC/DC Converter
DC input: 18 - 32 Volts
CDA-30: 5V@6A
CDB-30: +/-12V@1.2A
CDC-30: +/-15V@1.0A
CDG-30: 12V@2.5A
CDH-30: 15V@2.0A
Model No.:CDA/B/C/G/H-50
CDA/B/C/G/H-50 50 Watt DC/DC Converter
DC input: 18 - 32 Volts
CDA-50: 5V@10A
CDB-50: +/-12V@2A
CDC-50: +/-15V@0.6A
CDG-50: 12V@4A
CDH-50: 15V@3.3A
Model No.:CDA/F-500
CDA/F-500 500 Watt DC/DC Converter
DC input: 18 - 32 Volts
CDA-500: 5V@100A
CDF-500: 5V@50A; +/-15V@+/-8A
